SPECIFICATIONS	ML-8000	ML-64000	ML-32000	Evo Tre 16
Print
Printing Technology	PrecisionCore inkjet technology
Number of Print Head	8	64	32	16
Gradation process	Variable-Sized Droplet Technology
Max fabric thickness	Up to 5.0 mm	Up to 10 mm
Max print width	1,850 mm	1,800 mm	1,800 / 2,400 / 3,400 mm (71 / 94 / 133 in)	1,800 / 2,400 mm (71 / 94 in)
Max fabric width	1,850 mm	1,800 mm	1,800 / 2,400 / 3,400 mm (71 / 94 / 133 in)	1,800 / 2,400 mm (71 / 94 in)
GENESTA Ink
Reactive	-	Black, Cyan, Magenta, Yellow, Grey, Red, Blue, Orange, Crimson, Across (Ink penetration liquid)
Disperse	Black, Cyan, Magenta, Yellow, Grey, Red, Blue, Orange, Across (Ink penetration liquid)
Acid	Black, Cyan, Magenta, Yellow, Grey, Red, Blue, Cobalt, Orange, Rubine, Fluorescent Flavine, Flourescent Pink, Across (Ink penetration liquid)
Pigment	Black, Cyan, Magenta, Yellow, Grey, Red, Green, Orange
INK Capacity	10 liters
Print Speed (Square)*1
300 × 600 dpi, 1 pass	312 (m²/h) (Reactive/Pigment) 279 (m²/h) (Acid/Disperse) *2	-	697 (m²/h) *5	417 (m²/h) *5
600 × 600 dpi, 2 pass	162 (m²/h) (Reactive/Pigment) 144 (m²/h) (Acid/Disperse) *3	774 (m²/h)	423 (m²/h) *5	236 (m²/h) *5
900 × 600 dpi, 3 pass	108 (m²/h) (Reactive/Pigment) 96 (m²/h) (Acid/Disperse) *4	567 (m²/h)	305 (m²/h) *5	158 (m²/h) *5
Fabric Handling
Fabric Drive	Conveyer belt with thermoplastic adhesive	Conveyer belt with thermoplastic adhesive	Conveyer belt with adhesive
Belt Washing	Automatic
Standard Feeder
Fabric Roll Diameter	400 mm (15.7 in)	-	300 mm (11.8 in)
Fabric Roll Weight	100 kg (220 lb)	-	100 kg (220 lb)
Fabric Roll Core Diameter	2" or 3" (ML-32000-340 : 3" only)	-	2" or 3" (ML-32000-340 : 3" only)
Environmental Characteristics
Temperature	Operating: 20°C - 30°C, Recommended: 22°C - 28°C (Operating: 68°F - 86°F, Recommended: 72°F - 82°F)
Humidity	Operating: 40 - 60%RH (no condensation)
Dimensions
Printer	3,700 (W) x 2,690 (D) x 1,830 (H) (mm) 146 (W) x 106 (D) x 72 (H) (in)	6,500 (W) x 4,960 (D) x 2,530 (H) (mm) 256 (W) x 195 (D) x 100 (H) (in)	4,610 (W) x 2,500 (D) x 2,070 (H) (mm) *5 181 (W) x 98 (D) x 81 (H) (in)	4,610 (W) x 2,500 (D) x 2,070 (H) (mm) *5 181 (W) x 98 (D) x 81 (H) (in)
Control Box	-	1,600 (W) x 1,200 (D) x 2,640 (H) (mm) 63 (W) x 47 (D) x 104 (H) (in)	660 (W) x 1,500 (D) x 2,290 (H) (mm) *5 26 (W) x 59 (D) x 90 (H) (in)	480 (W) x 1,210 (D) x 1,920 (H) (mm) *5 19 (W) × 48 (D) × 76 (H) (in)
Ink Rack	880 (W) x 960 (D) x 790 (H) (mm) 35 (W) x 38 (D) x 31 (H) (in)	1,760 (W) x 960 (D) x 840 (H) (mm) 69 (W) x 38 (D) x 33 (H) (in)	Internal Ink Rack	1,240 (W) × 1,300 (D) × 1,220 (H) mm 49 (W) × 51 (D) × 48 (H) (in)
Weight
Printer	Approx. 2,150 kg (4,740 lb)	Approx. 7,000 kg (15,432 lb)	Approx. 3,900 kg (8,598 lb) *5	Approx. 3,700 kg (8,157 lb) *5
Control Box	-	Approx. 700 kg (1,543 lb)	Approx. 400 kg (882 lb)	Approx. 330 kg (728 lb)
Ink Rack	Approx. 110 kg (243 lb)	Approx. 300 kg (661 lb)	Approx. 240 kg (529 lb)	Approx. 260 kg (573 lb)
Electrical (Main unit)
Voltage	380 - 415 V, 3phase + Neutral + Earth, 50 Hz/60 Hz	400 V, 3phase + Neutral + Earth, 50 Hz/60 Hz
Rated Current	20 A	30 A	30 A	50 A
Apparent Power (Operating)	14.4 kVA	20.7 kVA	20.7 kVA	20.7 kVA
Network
Transmission speed	USB3.0 Ethernet 1000BASE-T	1000BASE-T (recommended)	100BASE-TX or more (recommended)

Note

• *1: Printing width: 1500 mm, Printing mode: bidirectional. Printing speeds vary depending on such factors as image printed, firmware version, operating state of PC and print settings.
• *2: With 300 x 300 dpi 2 Half Tone layers.
• *3: With 300 x 300 dpi 4 Half Tone layers.
• *4: With 300 x 300 dpi 6 Half Tone layers.

Printable Area and Accuracy:

• Maximum Printable Length:Unlimited
• Maximum Printable Width:1,800 mm (71”)
• Max. Fabric Width:1,800 mm (71”)

Roll Media Handling:

• Media Thickness:10mm

Printer Details:

• Belt Washing:Automatic
• Fabric Type:
  • Max. Fabric Thickness: 10.0mm
  • Fabric Drive: Conveyor belt with thermoplastic adhesive
• Weight:Approx. 7,000kg
• Display:22.82cm (9-INCH) LCD Touch Panel
• Other Features:
  • Printing Speed:
  • Square: Typical Printing Speed 1 (m2/h) 740 (600 x 600 dpi, 2 Pass); Typical Printing Speed 2 (m2/h) 533 (900 x 600 dpi, 3 Pass); Typical Printing Speed 1 (sq ft/hr) 7,965 (600 x 600 dpi, 2 Pass); Typical Printing Speed 2 (sq ft/hr) 5,737 (900 x 600 dpi, 3 Pass)
    Linear: Typical Printing Speed 1 (lmt/h) 493 (600 x 600 dpi, 2 Pass); Typical Printing Speed 2 (lmt/h) 355 (900 x 600 dpi, 3 Pass); Typical Printing Speed 1 (li ft/hr) 1,619 (600 x 600 dpi, 2 Pass); Typical Printing Speed 2 (li ft/hr) 1,166 (900 x 600 dpi, 3 Pass)
  • Printing Technology:
    PrecisionCore inkjet technology
  • Number of Print Head: 64
  • Number of Colour: 8
  • Print Resolution:1,200 x 1,200 dpi (Pigment), 1,200 x 600 dpi (Reactive, Acid, Disperse)
